Technical Data
| Display | LCD display |
| Protocol | WIFI, Zigbee, Modbus RS485, Bacnet option |
| Power Supply | AC24V or AC95-240V |
| Suitable | VAV system |
| Set Temp. Range | 5~35 ℃ |
| Ambient Temp. | 0~50 ℃ |
| Relative Humidity | 85% |
| Accurancy | ±0.5 ℃ |
| Modes | Heat/Cool/Ventilation Fan Mode |
| Fan Speed | 3 Speed Fan & Auto Fan |
| 0-10V Modulating Control | 0-10V for on off Valve Control/ Fan Speed Control/EC Fan option |
| Programmability | 7 days 4 periods ( Customizable) |
| Optional Function | Clock, Keycard, External Sensor etc. |
| Protection Class | IP20 |
| Thermostat Dimension | 86X86X14mm |
| Material | ABS+PC (Rohs certificated) |
| Certificate | CE(RED/EMC/LVD), Rohs |
| OEM & ODM | 1. Customized logo and package |
| 2. Customzied software ( change to customer’s user interface and control logic) | |
| 3. Customized hardware ( change the PCB and schematic based on the request) |
The ZoneEase VAV has PI control characteristics and is used for pressure-independent temperature control of VAV units in the comfort zone
in heating mode, and the cooling valve is opened for cooling mode. At the same time, the connected fan is activated depending on the control deviation and the set configuration.
A connectable remote sensor can be used either for detecting the room temperature or as a changeover sensor in 2-pipe systems or 4pipe.Window function/Keycard function
external sensor available .
